Flir
FLIR TG268 Spot Thermal Camera – 160 × 120 Spot IR Camera with Bullseye Laser
- SKU:
- 87505-0505
- UPC:
- 845188030551
- Availability:
- Usually ships in 3 business days
Description
The FLIR TG268 Spot Thermal Camera combines a thermal imager with a spot IR thermometer and Type K thermocouple input, so you can see the hot spot and measure it in the same tool.
It pairs a 160 × 120 thermal imager with FLIR MSX® image enhancement, a bullseye laser pointer for precise targeting, and a temperature range of -13°F to 752°F (-25°C to 400°C). The bright color display, pistol-grip housing, and drop-tested, IP-rated construction make it a grab-and-go tool for the truck, plant floor, or tool bag.
- Goes beyond single-spot IR thermometers to both see and evaluate hot and cold spots that can indicate serious issues
- 160 × 120 IR resolution with super resolution upscaling images to 320 × 240 for superior detail
- Patented FLIR MSX® (Multi-Spectral Dynamic Imaging) enhancement embosses visual scene details on full thermal images
- 24:1 spot ratio with bullseye laser and included Type-K thermocouple for contact measurements
- FLIR METERLiNK® app lets you capture and compare readings, analyze and share images and videos, and create reports
- Brilliant 2.4 inch screen reduces diagnostic time while simplifying repair and maintenance reporting
- Ideal for commercial electrical, facility maintenance, automotive, and HVAC applications
- IP54 rated and designed for 2 m drop
Typical Applications
- Electrical troubleshooting
- Mechanical inspections
- HVAC service
- Building checks
| Model | FLIR TG268 Spot Thermal Camera |
| IR Resolution | 160 × 120; Super Resolution 320 × 240 |
| Thermal Sensitivity/NETD | <50 mK |
| Accuracy | ±2.5% or 2.5°C (6°F) at 0°C to 50°C and 100°C to 400°C; ±3% or 3°C (7°F) at -25°C to 0°C |
| Field of view (FOV) | 57° × 44° |
| Image Modes | MSX; Visual with temperature reading |
| Display | 320 × 240, 2.4 in color LCD |
| Storage Media | 8 GB |
| Detector Pitch | 12 µm |
| Detector Type | Focal plane array (FPA), uncooled microbolometer |
| Focus | Focus free |
| Image Frequency | 8.7 Hz |
| Laser | Class 1 |
| Minimum Focus Distance | 0.3 m |
| Minimum Measurement Distance | 0.26 m |
| Spectral Range | 7.5 to 14 µm |
| Camera size (L x W x H) | 210 × 64 × 81 mm |
| Camera weight incl battery | 0.394 kg (13.9 oz) |
| Center spot | Yes |
| Measurement | Non-contact and contact (Type-K thermocouple) |
| Object Temperature Range | -25°C to 400°C (-13°F to 752°F) |
| Interface | USB 2.0, Bluetooth |
| METERLiNK | Yes |
| USB | USB Type-C |
| Battery operating time | 5 hours continuous scanning, 4.5 hours with laser on |
| Battery type | Rechargeable Li-ion battery, 3.7 V |
| Drop test | Designed for 2 m |
| Encapsulation | IP54 |
| Warranty | Flir 2-10 warranty |
| Included | TG268, Wrist Strap Lanyard, Pouch, USB Type-C cable, Type-K Thermocouple, Printed Documentation |
Specifications are subject to manufacturer updates. Refer to current FLIR product documentation for complete operating, safety and maintenance requirements.
FLIR Limited Warranty
The FLIR TG268 Spot Thermal Camera is covered by FLIR's standard limited warranty: 2 years on parts and labor and 10 years on the infrared detector, when the product is properly registered with FLIR within 60 days of the original retail purchase date.
Warranty eligibility, registration requirements, exclusions, and coverage are subject to FLIR's complete warranty terms.
